Tektronix TG8000 Service Manual

AG7 module replaceable parts list
AG7 module rep
laceable parts list
This section
contains a list of the replaceable modules for the AG7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, see Parts ordering information or Module servicing in the TG8000
mainframe replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard A NSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the AG7 module.
Table 3-3: AG7 module – replaceable parts
Fig. &
index
number
Tektronix part
number
Module no.
effective
Module no.
discont'd Qty Name & description
116-A001-05 1
EXCHANGE MODULE: AG7
3-5-
116-1168-00 1
EXCHANGE MODULE: AG7
-1 441-A267-03 1
CHASSIS, MODULE AG7: ASSY
-2 333-A404-00 1
PANEL, REAR: AG7, AL
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45 MM, LENGTH 11 MM, HEAD DIA 5 MM, HEAD
HEIGHT 2 MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
348-A128-00 116-A001-05
2.5 CM SHLD GASKET, ELEK: FINGER TYPE, 5.1 MM L X 6.4 MM W, BE-CU [97-645-02]
-5
348-A156-01 116-1168-00 1
GASKET, SHIELD; FINGER TYPE, BE-CU, 8.13 MM W X 2.79 MM H X 406.4 MM L
131-6383-00 116-A001-03 6
CONN, RF JACK: BNC, 50 OHM, FEMALE, STR, SNAP IN/PNL MTG, 12.5 MM
MLG [MCF3]
131-1315-01 116-A001-04 116-A001-04 6
CONN, RF, JACK; BNC, PNL, 50 OHM, FEMALE, STR, PELTOLA/PNL MNT, SILVER
ALLOY, 0.576 MLG X 0.366 TERMN, 0.375-32 THD, D-FLAT
Attached Parts
210-0012-00 STAR WASHER
220-0495-00 NUT
-6
131-8257-00 116-A001-05 6
CONNECTOR, PANEL MOUNT; BNC TO MCX
Attached Parts
210-0012-00 STAR WASHER
220-0495-00 NUT
-7
211-A245-01 4
SCREW, MACHINE: M3X6 MM L, PNH, STL, NI PL, CROSS REC, W/KOGATAMARU
& LOCK WASHER
174-A278-00 116-A001-03 6
CA ASSY, RF :75 OHM COAX, 120 MM L, BLACK [QQB-0120-0]
174-5660-00 116-A001-04 116-A001-04 6
CA ASSY, RF; 50 OHM COAX, 6.0 INCH LENGTH, PELTOLA TO RA-MCX; AG7
-8
174-5660-01 116-A001-05 6
CA ASSY, RF; 50 OHM COAX, 6.0 INCH LENGTH, MCX TO RA-MCX; AG7
-9 334-9399-00 1
MARKER, IDENT; BAR CODE LABEL, BASE 30, THERMAL LASTOMER
TG8000 Multiformat Test Signal Generator Service Manual 3–9
