Mainframe removal and installation procedures
General instructions
Read these gene
ral instructions before removing a module.
Read Equipment required below for a complete list of the tools you will need to
remove and ins
tall modules in the TG8000.
Review the figures on the following pages to locate the replaceable modules
in the instr
ument.
To remove a module for service, begin by reading the Acc ess procedure.(See
page 2-24.) By
following the instructions in that procedure, you can remove
the module to be serviced while removing the minimum number of additional
modules.
Equipment requ ired
Many of th
e modules in the TG8000 can be removed with a screwdriver handle
mounted with a #2 Phillips tip. Use this tool whenever a procedure step instructs
you to remove or install a screw unless a different size screwdriver is specifi ed
in that step.
All e quipment required to remove and reinstall each module is listed in the first
step of its procedure.
Table 2-5: Tools required for module removal
Item No. Name Description
1
Screwdriver handle
Accepts Phillips-driver bits
2
#1 Phillips tip Phillips-driver bit for #1 size screw heads
3
#2 Phillips tip Phillips-driver bit for #2 size screw heads
4
T15 TORX tip TORX-driver bit for T15 size screw heads
2–20 TG8000 Multiformat Test Signal Generator Service Manual
