BG7 module removal and replacement
BG7 module rem
oval and replacement
This section
contains the instructions on how you can remove and replace the
customer replaceable parts of the BG7 module.
CAUTION. To avoid d amage to this module, do not expose it to sprays, liquids, or
solvents. Do not flex the circuit board if you remove the board from its mounting
shield. The circuit board can be damaged by flexing. The shield provides
necessary structural support to the circuit board.
Required tools
The following tools are required to perform the removal and replacement
procedures:
Table 8-3: Required tools for removal and replacement of BG7 m odule
Name Description
Tektronix part
number
Screwdriver handle
Accepts Phillips-driver bits
#1 Phillips tip Phillips-driver bit for #1 size screws
#2 Phillips tip Phillips-driver bit for #2 size screws
Nut driver, 9/16 inch
deep socket
Nut driver for removing the BNC
connectors of the BG7 module
Nut driver, 14 mm
Special nut driver for removing the BNC
connectors of older BG7 modules
003-A041-00
TG8000 Multiformat Test Signal Generator Service Manual 8–13
