HDLG7 module replaceable parts list
HDLG7 module r
eplaceable parts list
This section
contains a list of the replaceable modules for the HDLG7 module.
Use this list to identify and order replacement parts.
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The follow
ing table s list the replaceable parts for the HDLG7 module.
Table 12-3: HDLG7 module – replaceable parts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
12-5- 116-1132-02 1
EXCHANGE MODULE, DUAL LINK HDLG7
-1 441-A269-02 1
CHASSIS ASSY; MAIN, HDLG7, AL, W/GASKET; SAFETY CONTROLLED
-2 333-4528-00 1
PANEL, REAR: HDLG7, SAFETY CONTROLLED
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM, HEAD
HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A156-01 1
GASKET, SHIELD; FINGER TYPE, BE-CU, 8.13MM W X 2.79MM H X 406.4MM L]
-6 174-5277-00
5
CABLE, RF, 75 OHM; 110 MM, BNC TO MCX75
-7
211-A245-01
5
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC, W/NUT & LOCK
WASHER, TG8000 OPT FP, AG7, AGL7, BG7, DVG7, HDVG7
-8 671-6184-00 1
CIRCUIT BD ASSY; DUAL LINK GENERATOR/CONVERTER, TESTED, WIRED
389386000
-9 334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUTDRIVER, BOX: 14 MM HEX, BNC RETAINING NUT, MODIFIED 19 MM
12–10 TG8000 Multiformat Test Signal Generator Service Manual
