GPS7 module removal and replacement
GPS7 module re
moval and replacement
This section
contains instructions on how to remove and repla ce the customer
parts of the GPS7 module.
CAUTION. To avoid d amage to this module, do not expose it to sprays, liquids, or
solvents. Do not flex the circuit board if you remove the board from its mounting
shield. The circuit board can be damaged by flexing. The shield provides
necessary structural support to the circuit board.
Required tools
Table 10-6: Required tools for GPS7 module removal and replacement
Name Description
Tektronix part
number
Screwdriver handle Accepts
1
/
4
inch screwdriver bits Standard tool
T10 TORX tip TORX driver bit for T10 size screw heads Standard tool
Flat or Phillips tip
Small tip for removing the module from the
mainframe
Standard tool
9
/
16
inch wrench
Wrench or deep nut driver, to remove nuts
from BNC connectors
Standard tool
3
/
16
inch socket Socket or nut driver to remove jackscrews
from DSUB connector
Standard tool
TG8000 Multiformat Test Signal Generator Service Manual 10–23
