Tektronix TG8000 Service Manual

AGL7 module replaceable parts list
AGL7 module re
placeable parts list
This section
contains a list of the replaceable modules for the AGL7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, see Parts ordering information or Module servicing in the TG8000
mainframe replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard A NSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the AGL7 module.
Table4-4:AGL7module–replaceableparts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
4-10- 116-A002-12 1
EXCHANGE MODULE: AGL7
4-10-1 441-A269-02 1
CHASSIS, MODULE AGL7: ASSY
-2 333-A405-00 1
PANEL, REAR: AGL7, AL
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A128-00 2.5
CM
SHLD GASKET, ELEK: FINGER TYPE, 5.1 MM L X 6.4 MM W, BE-CU [97-645-02]
-6 211-A245-01
5
SCREW, MACHINE: M3X6 MM L, PNH, STL, NI PL, CROSS REC,
W/KOGATAMARU & LOCK WASHER
-7
334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
-8 342-A146-00 1
INSULATOR, PLATE: HEAT CONDUCTOR, RUBBER, 20 MM X 20 MM X 100 M M
THK [TC1000-TKC]
-9 174-B847-00 6
CABLE ASSY, RF: 75 OHM COAX (RG179), 7.5 CM L, BNC TO MCX
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUTDRIVER, BOX: 14 MM HEX, BNC RETAINING NUT, MODIFIED 19 MM
TG8000 Multiformat Test Signal Generator Service Manual 4–21
