GPS7 module replaceable parts list
GPS7 module re
placeable parts list
This section
contains a list of the replaceable modules for the GPS7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, see Parts ordering information or Module servicing in the Mainframe
replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the GPS7 module.
Table 10-7: GPS7 module – replaceable parts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
10-5-1 352-1117-00 1
LIGHT PIPE SET: 1 BD CONN, 1 LIGHT PIPE, 1 LENS
-2 174-5509-00 1
CABLE, FEMALE SMB TO FEMALE BNC, 8.0 IN.
-3 214-3903-00 2
VENDOR: LYNTRON; SCREW, JACK; 4-40 X 0.312 LONG, 0.188 H HEX HEAD
STAND OFF, 4-40 INT THD, X 0.312 THD EXT 4-40, STEEL, SN PLATED
-4 214-4762-00 2
SPRING; CONICAL
-5
211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-6 210-1039-00 3
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-7
220-0497-00 3
NUT, PLAIN, HEX; .5-28 X .562 HEX, BRS, NI (NICKEL) PLATED
333–4575-00 B010100 B019999 1
PANEL, REAR; WITHOUT TIMECODE AND GENLOCK; SAFETY CONTROLLED
-8
333–4575-01 B020000
C020000
1
PANEL, REAR; WITH TIMECODE AND GENLOCK; SAFETY CONTROLLED
-9 441-2544-00 1
CHASSIS, MODULE
-10 211-0408-00 8
SCR, ASSY, WSHR; 4-40 X 0.250, PNH, STEEL, ZINC FINISH, T-10 TORX DR,
SEMS
116-1144-00 B010100 B019999 1
MODULE ASSEMBLY; GPS7 WITHOUT TIMECODE AND GENLOCK
-11
116-1157-05 B020000
C020000
1
MODULE ASSEMBLY; GPS7 WITH TIMECODE AND GENLOCK
-12 174-5521-00 1
CABLE, 2X4, 2MM PITCH, FEMALE TO FEMALE SQUARE PINS
-13 119–7518–00 1
MODULE, GPS; TIMING, 1PPS +/-15NS; 3.3V, 0.35W, 1575.42 MHZ L1; 2.6 X
1.3 X 0.33, TRIMBLE RESOLUTION T
-14 174-5511-00 1
CABLE, DSUB TO BOARD 15 CONDUCTOR
-15 343-1584-00 1
CLAMP; WIRE ROUTING, 0.51 H X 0.625 W, NYLON
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
10–26 TG8000 Multiformat Test Signal Generator Service Manual
