ATG7 module replaceable parts list
ATG7 module re
placeable parts list
This section
contains a list of the replaceable modules for the ATG7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, see Parts ordering information or Module servicing in the TG8000
mainframe replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the ATG7 module.
Table 5-4: ATG7 module – replaceable parts
Fig. &
index
number
Tektron
ix part
number
Serial n
o.
effective
Serial n
o.
discont'd Qty Name & description
5-9- 116-A014-04 1
EXCHANGE MODULE: ATG7
5-9-1 441-A269-02 1
CHASSIS, MODULE AGL7: ASSY
-2 333-A427-00 1
PANEL, REAR: ATG7, AL
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM, HEAD
HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A128-00
2.5 CM SHLD GASKET, ELEK: FINGER TYPE, 5.1MM LX6.4MM W, BE-CU [97-645-02]
-6 174-B851-00 4
CABLE ASSY,RF:75OHM COAX(RG179),5.5CM L,BNC TO MCX
-7
211-A245-01
5
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC, W/KOGATAMARU
&LOCKWASHER
-8 334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUTDRIVER, BOX: 14MM HEX, BNC RETAINING NUT, MODIFIED 19MM
5–16 TG8000 Multiformat Test Signal Generator Service Manual
