Preface
Manual conventions
This manual uses certain conventions with which you should become familiar.
Some sections of the manual contain procedures for you to perform. To keep those
instructions clear and consistent, this manual uses the following conventions:
Names of front panel controls and menus appear in the same case (initial
capitals, all uppercase, etc.) in the manual as is used on the TG8000 front
panel and menus.
Instruction steps are numbered unless there is only one step.
Bold text refers to specific interface elements that you are instructed to select,
click, or clear.
Example: Press the ENTER button to access the PRESET submenu.
Italic t
ext refers to document names or sections. Italics are also used in
NOTES, CAUTIONS, and WARNINGS.
Exampl
e: The Diagrams section includes a block diagram and an
interconnect diagram.
Modules
Throughout this manual, the term module appears. A module is composed of
elec
trical and mechanical assemblies, circuit cards, and interconnecting cables.
References to a module are different than references to a product module such as
“AGL7 Genlock module” which is a product installed in the TG8000 mainframe.
Safety
Sym
bols and terms related to safety appear in the General safety summary.
xx TG8000 M ultiformat Test Signal Generator Service Manual
