HDVG7 module removal and replacement
HDVG7 module r
emoval and replacement
This section
contains the instructions on how you can remove and replace the
customer replaceable parts of the HDVG7 module.
CAUTION. To avoid damage to this module, do not expose it to sprays, liquids, or
solvents. Do not flex the c ircuit board if you remove the board from its mounting
shield. The circuit board can be damaged by flexing. The shield provides
necessary structural support to the circuit board.
Required tools
The following tools are required to perform the removal and replacement
procedures:
Table 13-4: Required tools for removal and replacement of the HDVG7 module
Name Description
Tektronix part
number
Screwdriver handle
Accepts Phillips-driver bits
#1 Phillips tip Phillips-driver bit for #1 size screw heads
#2 Phillips tip Phillips-driver bit for #2 size screw heads
Nut driver, 9/16 inch
deep socket
Nut d river for removing the BNC
connectors of the HDVG7 module
Nut driver, 14 mm
Special nut driver for removing the BNC
connectors of older HDVG7 modules
003-A041-00
13–16 TG8000 Multiformat Test Signal Generator Service Manual
