Module installation and removal
Figure 1-5: Removing a module
5. If this empty slot w ill not be used, you must attach a blank panel to the
mainframe to control instrument cooling and EMI emissions.
a. Align the blank panel with the open slot of the mainframe.
b. Tighten the two screws to secure the blank panel to the mainframe.
NOTE. A blank panel is available as an optional accessory for the
TG8000 mainframe.
6. If you want to install another module into the slot from which the module is
removed, perform To install a Module starting at step 4. (See page 1-11.)
TG8000 Multiformat Test Signal Generator Service Manual 1–15
