Tektronix TG8000 Service Manual

HDVG7 module replaceable parts list
HDVG7 module r
eplaceable parts list
This section
contains a list of the replaceable modules for the HDVG7 module.
Use this list to identify and order replacement parts.
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The follow
ing tables list the replaceable parts for the HDVG7 module.
Table 13-5: HDVG7 module – replaceable parts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
116-A007-10 1
EXCHANGE MODULE: HDVG7
13-6-
116-A008-10 1
EXCHANGE MODULE: HDVG7-BK
13-6-1 441-A275-00 1
CHASSIS, MODULE HDVG7: ASSY
333-A409-00 1
PANEL, REAR: HDVG7, AL
-2
333-A410-00 1
PANEL, REAR: HDVG7 OPTION, AL
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A128-00 2.5
CM
SHLD GASKET, ELEK: FINGER TYPE, 5.1MM LX6.4MM W, BE-CU [97-645-02]
174-B846-00 2
CABLE ASSY, RF: 75 OHM, COAX (RG179), 6 CM L, BNC TO PL71-LP-1.5C
-6
174-B846-00 4
CABLE ASSY, RF: 75 OHM, COAX (RG179), 6 CM L, BNC TO PL71-LP-1.5C
(OPTION BK)
-7
211-A245-01 6
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC,
W/KOGATAMARU & LOCK WASHER
-8 334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
342-A146-00 1
INSULATOR, PLATE: HEAT CONDUCTOR, RUBBER, 20MMX20MMX10MM THK
[TC1000-TCK]
-9
342-A146-00 2
INSULATOR, PLATE: HEAT CONDUCTOR, RUBBER, 20MMX20MMX10MM THK
[TC1000-TCK]
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUT DRIVER, BOX: 14 MM HEX, BNC RETAINING NUT, MODIFIED 19 MM
13–18 TG8000 Multiformat Test Signal Generator Service Manual
