Mainframe replaceable parts list
Table 2-9: Fron
t Panel assembly replaceable parts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
2-17- 650-5546-00 1
FRONT PANEL ASSY, TG8000
Subparts
-1 367-0530-00 2
HANDLE, BOW; AL, 1.0 X 1.25, STAIN FINISH, SAFETY CONTROLLED
-2 335-2800-00 1
LABEL, FRONT PANEL TG8000, SAFETY CONTROLLED
-3 426-2637-00 1
FRONT PANEL BEZEL, SAFETY CONTROLLED
-4 348-2061-00 1
GASKET, DISPLAY DUST SEAL
-5
211-A245-01 13
SCREW, MACHINE; M3 X 6 MM L, PNH, STL, NI PL, CROSS REC, W /NUT & LOCK
WASHER
-6 119-7930-00 1
DISPLAY MODULE ASSEMBLY, SAFETY CONTROLLED
-7
407-5661-00 1
FRONT PANEL SUPPORT BRACKET, SAFETY CONTROLLED
-8 211-0738-00 4
SCREW, MACHINE; 6-32 X 0.625, PNH, STL BLK ZI, TORX
-9 174-6136-00 1
CABLE, RIBBON, LCD, 2X8, 0.100 P FEMALE TO FEMALE
-10 131-6643-00 10
CONTACT, ELEC; GROUNDING, 0.169 L, 0.320 DEEP, ELECTROLESS NICKEL;
TDS3012
-11 174-6135-00 1
CABLE 2 X 13, RIBBON, KEYBOARD FEMALE TO F EMALE
-12 131-6521-00 1
CONTACT, ELEC; EMI, CLIP-ON, 0.38 L X 0.460 W (2 CONTACTS) X 0.45 HIGH,
ELECTROLESS NICKEL PLATE
-13 878-0649-00 1
CIRCUIT BOARD ASSY; FRONT PANEL, UNTESTED
-14 260-2951-00 1
SWITCH KEYPAD (ELASTOMERIC MAT, TG8000), SAFETY CONTROLLED
2–40 TG8000 Multiformat Test Signal Generator Service Manual
