Tektronix TG8000

DVG7 module replaceable parts list
DVG7 module re
placeable parts list
This section
contains a list of the replaceable modules for the DVG7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, see Parts ordering information or Module servicing in the Mainframe
replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the DVG7 module.
Table 9-5: DVG7 module – replaceable parts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
116-A005-09 1
EXCHANGE MODULE: DVG7
9-6-
116-A006-09 1
EXCHANGE MODULE: DVG7-BK
9-6-1 441-A273-03 1
CHASSIS, MODULE DVG7: ASSY
333-A407-00 1
PANEL, REAR: DVG7, AL
-2
333-A408-00 1
PANEL, REAR: DVG7 OPTION, AL
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A128-00 2.5
CM
SHLD GASKET, ELEK: FINGER TYPE, 5.1MM LX6.4MM W, BE-CU [97-645-02]
-6 174-B846-00 2
CABLE ASSY, RF:75 OHM, COAX (RG179), 6 CM L, BNC TO PL71-LP-1.5C
174-B846-00 4
CABLE ASSY, RF:75 OHM, COAX (RG179), 6 CM L, BNC TO PL71-LP-1.5C
(OPTION BK)
211-A245-01 8
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC,
W/KOGATAMARU & LOCK WASHER
-7
211-A245-01 6
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC,
W/KOGATAMARU & LOCK WASHER (OPTION BK)
-8 334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUT DRIVER, BOX: 14 MM HEX, BNC RETAINING NUT, MODIFIED 19 MM
9–18 TG8000 Multiformat Test Signal Generator Service Manual
