Texas Instruments MSP430 User Guide

MSP-TS430RGC64C www.ti.com
106
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-25. MSP-TS430RGC64C Bill of Materials
Item Qty Reference Value Description Comment Supplier No.
1 0 C1, C2 12pF CAP, SMD, Ceramic, 0805 DNP C1 C2
2 0 C3, C4 CAP, SMD, Ceramic, 0805 DNP C3 C4
4 3 C5, C7, C10 10uF CAP, SMD, Ceramic, 0805
5 5 C8 C6 C13-15 100nF CAP, SMD, Ceramic, 0805 Digi-Key: 311-1245-2-ND
5 5 C8 2.2nF CAP, SMD, Ceramic, 0805
6 1 C9 470nF CAP, SMD, Ceramic, 0805 Digi-Key: 478-1403-2-ND
7 1 C16 4.7uF CAP, SMD, Ceramic, 0805
8 1 D1 Green LED LED, SMD, 0805
9 4 J1-J4 16-pin header
Pin header 1x16: Grid: 100mil
(2.54 mm)
DNP: headers and
receptacles enclosed with
kit. Keep vias free of solder.
: Header
: Receptacle
SAM1029-16-ND
SAM1213-16-ND
10 2 J5, J6 3-pin header, male, TH
Pin header 1x3: Grid: 100mil (2.54
mm)
SAM1035-03-ND
11
JP5, JP6, JP7,
JP8, JP9, JP10
3-pin header, male, TH
Pinheader 1x3: Grid: 100mil (2.54
mm)
place jumpers on pins 2-3 SAM1035-03-ND
12 JP3 3-pin header, male, TH
Pin header 1x3: Grid: 100mil (2.54
mm)
place jumper on pins 1-2 SAM1035-03-ND
13 JP1, JP2, JP4 2-pin header, male, TH
Pin header 1x2; Grid: 100mil (2.54
mm)
place jumper on header SAM1035-02-ND
14 10 Jumper
Place on: JP1, JP2, JP3,
JP4, JP5, JP6, JP7, JP8,
JP9, JP10
15-38-1024-ND
15 1 JTAG 2x7Pin,Wanne
Header, THD, Male 2x7 Pin,
Wanne, 100mil spacing
HRP14H-ND
16 0 BOOTST 2x5Pin,Wanne
Header, THD, Male 2x5 Pin,
Wanne, 100mil spacing
DNP
17 1 Q1 26MHz/ASX53 CRYSTAL, SMD, 5x3MM, 26MHz Only Kit.
18 0 Q2 26MHz/ASX53 CRYSTAL, SMD, 5x3MM, 26MHz 300-8219-1-ND
19 1 D3 LL103A DIODE, SMD, SOD123, Schottky Buerklin: 24S3406
20 2 R3, R7 330 Ohm, SMD0805 541-330ATR-ND
21 1 R5 47k Ohm, SMD0805 RES, SMD, 0805, 1/8W, x% 541-47000ATR-ND
22
R1, R2, R4, R6,
R8, R9, R10,
R11, R12
0 Ohm, SMD0805 RES, SMD, 0805, 1/8W, x%
DNP: R6, R8, R9, R10,
R11,R12
541-000ATR-ND
23 1 U1 Socket: QFN11T064-006-N-HSP Manuf.: Yamaichi
24 2 MSP430 MSP430F5229IRGCR
IC, MCU, SMD, 9.15x9.15mm
Thermal Pad with Socket
25 4 Rubber stand off Rubber stand off
apply to corners at bottom
side
Buerklin: 20H1724
26 1 PCB 84 x 76 mm 84 x 76 mm
