www.ti.com
EM430F5137RF900
155
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-40. EM430F5137RF900 Bill of Materials
Item Reference
No. per
Board
Description Value
Manufacturer's Part
Number
Manufacturer Comment
1 Q1 1
( CUSTOMER SUPPLY )
CRYSTAL, SMT, 4P, 26MHz
26M ASX-531(CS)
AKER
ELECTRONIC
2
C1-C5, C082,
C222, C271,
C281, C311,
C321, C341,
C412, C452
14
CAPACITOR, SMT, 0402, CER,
16V, 10%, 0.1uF
0.1uF 0402YC104KAT2A AVX
3 C071 1
CAPACITOR, SMT, 0603,
CERAMIC, 0.47uF, 16V, 10%,
X5R
0.47uF 0603YD474KAT2A AVX
4 R401 1 RES0402, 47.0K 47kΩ CRCW04024702F100 DALE
5 CON11 1
HEADER, THU, MALE, 14P,
2X7, 25.4x9.2x9.45mm
09 18 514 6323 HARTING
6 CON10 0
HEADER, THU, MALE, 10P,
2X5, 20.32x9.2x9.45mm
09 18 510 6323 HARTING DNP
7 D1 1 LED, SMT, 0603, GREEN, 2.1V active APT1608MGC KINGBRIGHT
8 D2 1 LED, SMT, 0603, RED, 2.0V active APT1608EC KINGBRIGHT
9 Q3 0
UNINSTALLED CRYSTAL, SMT,
3P, MS1V (Customer Supply)
32.768k MS1V-T1K (UN)
MICRO
CRYSTAL
DNP
10 CON12 1
HEADER, THU, MALE, 3P, 1x3,
9.9x4.9x5.9mm
22-03-5035 MOLEX
11 C251, C261 2 50V, 5%, 27pF 27pF GRM36COG270J50 MURATA
12 L341 1
FERRITE, SMT, 0402, 1.0kΩ,
250mA
1kΩ BLM15HG102SN1D MURATA
13 C293 1
CAPACITOR, SMT, 0402,
CERAMIC, 100pF, 50V, 0.25pF,
C0G(NP0)
100pF GRM1555C1H101JZ01 MURATA
14 L304 1
INDUCTOR, SMT, 0402, 2.2nH,
0.1nH, 220mA, 500MHz
0.0022u
H
LQP15MN2N2B02 MURATA
15 L303, L305 2
INDUCTOR, SMT, 0402, 15nH,
2%, 450mA, 250MHz
0.015uH LQW15AN15NG00 MURATA
16 L292, L302 2
INDUCTOR, SMT, 0402, 18nH,
2%, 370mA, 250MHz
0.018uH LQW15AN18NG00 MURATA
17 C291 1
CAPACITOR, SMT, 0402,
CERAMIC, 1pF, 50V, 0.05pF,
C0G(NP0)
1pF GRM1555C1H1R0WZ01 MURATA
18 C303 1
CAPACITOR, SMT, 0402,
CERAMIC, 8.2pF, 50V, 0.05pF,
C0G(NP0)
8.2pF GRM1555C1H8R2WZ01 MURATA
19
C292, C301-
C302, C304
4
CAPACITOR, SMT, 0402,
CERAMIC, 1.5pF, 50V, 0.05pF,
C0G(NP0)
1.5pF GRM1555C1H1R5WZ01 MURATA
20 L291, L301 2
INDUCTOR, SMT, 0402, 12nH,
2%, 500mA, 250MHz
0.012uH LQW15AN12NG00 MURATA
21
C282, C312,
C351, C361,
C371
5
CAPACITOR, SMT, 0402,
CERAMIC, 2pF, 50V, 0.1pF,
C0G
2.0pF GRM1555C1H2R0BZ01 Murata
22 L1 1
INDUCTOR, SMT, 0402, 6.2nH,
0.1nH, 130mA, 500MHz
6.2nH LQP15MN6N2B02 Murata
23 S1-S2 2
ULTRA-SMALL TACTILE
SWITCH, SMT, 2P, SPST-NO,
1.2x3x2.5mm, 0.05A, 12V
B3U-1000P OMRON
24
R4-R5, R051,
R061, R431,
R441
0
UNINSTALLED
RESISTOR/JUMPER, SMT,
0402, 0 Ω, 5%, 1/16W
0Ω ERJ-2GE0R00X PANASONIC DNP
24a R7 1
RESISTOR/JUMPER, SMT,
0402, 0 Ω, 5%, 1/16W
0Ω ERJ-2GE0R00X PANASONIC
To Next Page
