www.ti.com
MSP-TS430DL48
81
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-17. MSP-TS430DL48 Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
2 C4, C7 2 10uF, 10V, Tantal Size B 511-1463-2-ND
3 C3, C5 2 100nF, SMD0805 478-3351-2-ND
4 C8 1 10nF, SMD0805 478-1383-2-ND
5 D1 1 yellow LED, TH, 3mm, T1 511-1251-ND
6 J1, J2 0 24-pin header, TH
DNP: Headers and
receptacles enclosed with
kit.Keep vias free of solder.
SAM1034-12-ND : Header
SAM1212-12-ND : Receptacle
7 J3, JP1, JP2 2 3-pin header, male, TH SAM1035-03-ND
Place jumper on header JP1;
Pos 1-2. DNP: JP2
8 J4, J5 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 3 Jumper 15-38-1024-ND Place on: JP1, J4, J5
10 JTAG 1 14-pin connector, male, TH HRP14H-ND
11 BOOTST 0 10-pin connector, male, TH
DNP: Keep vias free of
solder
12 Q1 0 Crystal
Micro Crystal MS1V-T1K
32.768kHz, C(Load) =
12.5pF
DNP: Keep vias free of
solder
13 R3 1 560 Ω, SMD0805 541-560ATR-ND
14
R4, R6, R7,
R12
2 0 Ω, SMD0805 541-000ATR-ND DNP: R6, R7
15 R5 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: IC51-1387 KS-15186 Manuf.: Yamaichi
17 PCB 1 58 x 66 mm 2 layers
18
Adhesive
Plastic feet
4 ~6mm width, 2mm height
for example, 3M Bumpons
Part No. SJ-5302
Apply to corners at bottom
side
19 MSP430 2 MSP430F4270IDL
DNP: Enclosed with kit
supplied by TI
