1.1 Kit Contents, MSP-TS430xx
• One READ ME FIRST document
• One 32.768-kHz crystal from Micro Crystal (except MSP-TS430PW24)
• One target socket module
• A 2×7-pin male JTAG connector is also present on the PCB (see different setup for L092)
• MSP430 device samples (see Table 1-1 for sample type)
Table 1-1. Individual Kit Contents, MSP-TS430xx
Part Number Socket Type Supported Devices Included Devices Headers and Comment
MSP-TS430D8
(green PCB)
8-pin D
(TSSOP ZIF)
MSP430G2210, MSP430G2230
1 x MSP430G2210ID and
1 x MSP430G2230ID
Two PCB 1×4-pin headers (two
male and two female)
MSP-TS430PW14
(green PCB)
14-pin PW
(TSSOP ZIF)
MSP430F20xx, MSP430G2x01,
MSP430G2x11, MSP430G2x21,
MSP430G2x31
2 x MSP430F2013IPW
Four PCB 1×7-pin headers (two
male and two female)
MSP-TS430L092
(green PCB)
14-pin PW
(TSSOP ZIF)
MSP-TS430L092 2 x MSP430L092IPW
Four PCB 1×7-pin headers (two
male and two female). A "Micro-
MaTch" 10-pin female connector is
also present on the PCB which
connects the kit with an ' Active
Cable' PCB; this 'Active Cable'
PCB is connected by 14-pin JTAG
cable with the FET430UIF
MSP-TS430PW20
(green PCB)
20-pin PW
(TSSOP ZIF)
MSP430FR2311IPW20,
MSP430FR2311IPW16
None. Free samples can
be ordered in the TI Store.
Four PCB 1×12-pin headers (two
male and two female)
MSP-TS430PW24
(green PCB)
24-pin PW
(TSSOP ZIF)
MSP430AFE2xx 2 x MSP430AFE253IPW
Four PCB 1×12-pin headers (two
male and two female)
MSP-TS430RGE24A
(red PCB)
24-pin RGE
(QFN ZIF)
MSP430FR2433IRGE
None. Free samples can
be ordered in the TI Store.
Four PCB 1×6-pin headers (two
male and two female)
MSP-TS430DW28
(green PCB)
28-pin DW
(SSOP ZIF)
MSP430F11x1, MSP430F11x2,
MSP430F12x, MSP430F12x2,
MSP430F21xx
Supports devices in 20- and 28-pin
DA packages
2 x MSP430F123IDW
Four PCB 1×12-pin headers (two
male and two female)
MSP-TS430PW28
(green PCB)
28-pin PW
(TSSOP ZIF)
MSP430F11x1, MSP430F11x2,
MSP430F12x, MSP430F12x2,
MSP430F21xx
2 x MSP430F2132IPW
Four PCB 1×12-pin headers (two
male and two female)
MSP-TS430PW28A
(red PCB)
28-pin PW
(TSSOP ZIF)
MSP430F20xx, MSP430G2xxx in
14-, 20-, and 28-pin PW packages,
MSP430TCH5E in PW package
2 x MSP430G2452IPW20
Four PCB 1×12-pin headers (two
male and two female)
MSP-TS430RHB32A
(red PCB)
32-pin RHB
(QFN ZIF)
MSP430i204x 2 x MSP430i2041TRHB
Eight PCB 1×8-pin headers (four
male and four female)
MSP-TS430DA38
(green PCB)
38-pin DA
(TSSOP ZIF)
MSP430F22xx, MSP430G2x44,
MSP430G2x55
2 x MSP430F2274IDA
2 x MSP430G2744IDA
2 x MSP430G2955IDA
Four PCB 1×19-pin headers (two
male and two female)
MSP-TS430QFN23x0
(green PCB)
40-pin RHA
(QFN ZIF)
MSP430F23x0 2 x MSP430F2370IRHA
Eight PCB 1×10-pin headers (four
male and four female)
MSP-TS430RSB40
(green PCB)
40-pin RSB
(QFN ZIF)
MSP430F51x1, MSP430F51x2 2 x MSP430F5172IRSB
Eight PCB 1×10-pin headers (four
male and four female)
MSP-TS430RHA40A
(red PCB)
40-pin RHA
(QFN ZIF)
MSP430FR572x, MSP430FR573x 2 x MSP430FR5739IRHA
Eight PCB 1×10-pin headers (four
male and four female)
MSP-TS430DL48
(green PCB)
48-pin DL
(TSSOP ZIF)
MSP430F42x0 2 x MSP430F4270IDL
Four PCB 2×12-pin headers (two
male and two female)
MSP-TS430RGZ48B
(blue PCB)
48-pin RGZ
(QFN ZIF)
MSP430F534x 2 x MSP430F5342IRGZ
Eight PCB 1×12-pin headers (four
male and four female)
MSP-TS430RGZ48C
(black PCB)
48-pin RGZ
(QFN ZIF)
MSP430FR58xx and
MSP430FR59xx
2 x MSP430FR5969IRGZ
Eight PCB 1×12-pin headers (four
male and four female)
MSP-TS430PM64
(green PCB)
64-pin PM
(QFP ZIF)
MSP430F13x, MSP430F14x,
MSP430F14x1, MSP430F15x,
MSP430F16x, MSP430F16x1,
MSP430F23x, MSP430F24x,
MSP430F24xx, MSP430F261x,
MSP430F41x, MSP430F42x,
MSP430F42xA, MSP430FE42x,
MSP430FE42xA, MSP430FE42x2,
MSP430FW42x
TS Kit:
2 x MSP430F2618IPM;
FET Kit:
2 x MSP430F417IPM and
2 x MSP430F169IPM
Eight PCB 1×16-pin headers (four
male and four female)
