MSP-TS430PZ100A
129
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-32. MSP-TS430PZ100A Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
1b C3, C4 0 47pF, SMD0805
DNP: Only recommendation.
Check your crystal spec.
2 C7, C9 2 10uF, 10V, Tantal Size B 511-1463-2-ND
3 C5, C11, C14 3 100nF, SMD0805 311-1245-2-ND
4 C8 1 10nF, SMD0805 478-1358-1-ND
5 C6 0 470nF, SMD0805 478-1403-2-ND DNP
6 D1 1 green LED, SMD0805 67-1553-1-ND
7 J1, J2, J3, J4 0 25-pin header, TH
DNP: Headers and
receptacles enclosed with
kit.Keep vias free of solder.
SAM1029-25-ND : Header
SAM1213-25-ND : Receptacle
8 J5 1 3-pin header, male, TH SAM1035-03-ND
10 JP1, JP2 2 2-pin header, male, TH SAM1035-02-ND pPlace jumper on header
11 JP3 1 3-pin header, male, TH SAM1035-03-ND Place jumper on pins 1-2
12 3 Jumper 15-38-1024-ND Place on: JP1, JP2, JP3
13 JTAG 1 14-pin connector, male, TH HRP14H-ND
14 BOOTST 0 10-pin connector, male, TH
DNP: Keep vias free of
solder
15 Q1, Q2 0 Crystal
Q1: Micro Crystal MS1V-T1K
32.768kHz, C(Load) =
12.5pF
DNP: Keep vias free of
solder
16 R3 1 330 Ω, SMD0805 541-330ATR-ND
17
R1, R2, R4,
R6, R7, R8,
R9, R10,
R11, R12
2 0 Ω, SMD0805 541-000ATR-ND
DNP: R4, R6, R7, R8, R9,
R10, R11, R12
18 R5 1 47k Ω, SMD0805 541-47000ATR-ND
19 U1 1 Socket: IC357-1004-53N Manuf.: Yamaichi
20 PCB 1 90 x 82 mm 4 layers
21
Rubber
standoff
4 Select appropriate
Apply to corners at bottom
side
22 MSP430 2 MSP430F47197IPZ
DNP: Enclosed with kit
supplied by TI
