MSP-TS430RHA40A
www.ti.com
78
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-16. MSP-TS430RHA40A Bill of Materials
Position Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP: C1, C2
2 C5 0 2.2nF, SMD0805 DNP C12
3 C3, C7 2 10uF, 10V, SMD0805 5 DNP C11
4 C4, C6 2 100nF, SMD0805 478-3351-2-ND
5 C9 1 470nF, SMD0805
6 D1 1 green LED, SMD0805 P516TR-ND
7
J1, J2, J3,
J4
4 10-pin header, TH
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
: Header
: Receptacle
7.1 4 10-pin header, TH
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
: Header
: Receptacle
8
J5, JP1,
JP4, JP5,
JP6, JP7,
JP8, JP9
8 3-pin header, male, TH SAM1035-03-ND
Place jumper on 1-2 of JP4-JP9; Place
on 1-2 on JP1
9 JP2, JP3 2 2-pin header, male, TH SAM1035-02-ND place jumper on header
10 9 Jumper 15-38-1024-ND see Pos 8 an 9
11 JTAG 1
14-pin connector, male,
TH
HRP14H-ND
12 BOOTST 0
10-pin connector, male,
TH
DNP. Keep vias free of solder
13 U1 1 Socket: QFN-40B-0.5-01 Manuf.: Enplas
14 Q1 0 Crystal
Micro Crystal MS3V-T1R
32.768kHz, C(Load) =
12.5pF
DNP: Q1. Keep vias free of solder
15 R1,R7 2 330R SMD0805 541-330ATR-ND
16
R2, R3, R5,
R6, R8, R9,
2 0 Ohm, SMD0805 541-000ATR-ND DNP:R2, R3, R5, R6
17 R4 1 47k SMD0805
18 PCB 1 79 x 66 mm 2 layers
19
Rubber
stand off
4
select appropriate; for
example, Buerklin:
20H1724
apply to corners at bottom side
20 MSP430 2 MSP430N5736IRHA DNP: enclosed with kit. Is supplied by TI
