www.ti.com
MSP-TS430PW28A
63
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-11. MSP-TS430PW28A Bill of Materials
Position Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
2 C5 1 2.2nF, SMD0805
3 C3 1 10uF, 10V, SMD0805
4 C4, C6, 2 100nF, SMD0805 478-3351-2-ND
5 D1 1 green LED, SMD0805 P516TR-ND
6 J1, J2 0 14-pin header, TH
DNP: Headers and receptacles
enclosed with kit. Keep vias free of
solder: (Header and Receptacle)
7
J5, JP1,
JP4, JP5,
JP6, JP7,
JP8, JP9
8 3-pin header, male, TH SAM1035-03-ND
Place jumper on 1-2 of JP4-JP9 Place
on 1-2 on JP1
8 JP2, JP3 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 9 Jumper 15-38-1024-ND see Pos 7 an 8
10 JTAG 1
14-pin connector, male,
TH
HRP14H-ND
11 BOOTST 0 DNP Keep vias free of solder
12 Q1 0 Crystal
Micro Crystal MS3V
32.768kHz, C(Load) =
12.5pF
DNP: keep vias free of solder
13 R1, R7 2 330 Ω, SMD0805 541-330ATR-ND
14
R2, R3,R5,
R6,
0 0 Ohm, SMD0805 541-000ATR-ND DNP R2, R3,R5, R6
15 R4 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: OTS-28-0.65-01 Manuf.: Enplas
17 PCB 1 63.5 x 64.8 mm 2 layers
18
Adhesive
plastic feet
4
Approximately 6mm width,
2mm height
for example, 3M Bumpons
Part No. SJ-5302
Apply to corners at bottom side
19 MSP430 2 MSP430G2553IPW28 DNP: enclosed with kit, supplied by TI
