Hardware
Table B-13. MSP-TS430DA38 Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
2 C7 1 10uF, 10V, Tantal Size B 511-1463-2-ND
3 C5 1 100nF, SMD0805 478-3351-2-ND
4 C8 0 2.2nF, SMD0805 DNP
5 D1 1 green LED, SMD0603 475-1056-2-ND
6 J1, J2 0 19-pin header, TH
DNP: headers and
receptacles enclosed with
kit.Keep vias free of solder.
SAM1029-19-ND : Header
SAM1213-19-ND : Receptacle
7
"J3, JP1,
JP4, JP5,
JP6, JP7,
JP8, JP9"
8 3-pin header, male, TH SAM1035-03-ND
Place jumpers on headers
JP1, JP4,JP5, JP6, JP7, JP8,
JP9; Pos 1-2
8 JP2, JP3 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 9 Jumper 15-38-1024-ND Place on: JP1 - JP9; Pos 1-2
10 JTAG 1 14-pin connector, male, TH HRP14H-ND
11 BOOTST 0 10-pin connector, male, TH
DNP: Keep vias free of
solder
12 Q1 0 Crystal
Micro Crystal MS1V-T1K
32.768kHz, C(Load) =
12.5pF
DNP: Keep vias free of
solder
13 R1, R3 2 330 Ω, SMD0805 541-330ATR-ND
14 R10, R11 0 0 Ω, SMD0805 541-000ATR-ND DNP
15 R5 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: IC189-0382--037 Manuf.: Yamaichi
17 PCB 1 67 x 66 mm 2 layers
18
Adhesive
Plastic feet
4 ~6mm width, 2mm height
for example, 3M Bumpons
Part No. SJ-5302
Apply to corners at bottom
side
19 MSP430 2 MSP430F2274IDA
DNP: enclosed with kit
supplied by TI
