MSP-TS430PW28
www.ti.com
60
SLAU278YMay 2009Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
(1)
PCB 66 x 79 mm, two layers; Rubber stand off, four pieces
Table B-10. MSP-TS430PW28 Bill of Materials
(1)
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805
DNP: C1, C2 , Cover holes
while soldering
2 C3 1 10uF, 10V Tantal Elko B
3 C4 1 100nF, SMD0805
4 C5 0 2.2nF, SMD0805 DNP
5 D1 1 LED green SMD0603
6 Q1 0 QUARZ, Crystal
Micro Crystal MS1V-T1K
32.768kHz, C(Load) =
12.5pF
DNP: Cover holes and
neighboring holes while
soldering
7 J1, J2 2 14-pin header, TH male
DNP: Headers and
receptacles enclosed with
kit.Keep vias free of solder.
: Header
: Receptacle
7.1 2 14-pin header, TH female
DNP: headers and
receptacles enclosed with
kit.Keep vias free of solder.
: Header
: Receptacle
8 J5, IP1 1 3-Pin Connector , male
8a
JP1, JP4,
JP5, JP6,
JP7, JP8,
JP9
7 3-Pin Connector , male Jumper on Pos 1-2
9 JP2, JP3 2 2-Pin Connector , male with Jumper
10 BOOTST 0 ML10, 10-Pin Conn. , m RS: 482-115
DNP: Cover holes while
soldering
11 JTAG 1 ML14, 14-Pin Conn. , m RS: 482-121
12 R1, R7 2 330R, SMD0805
12
R2, R3, R5,
R6
0 0R, SMD0805 DNP
14 R4 1 47K, SMD0805
15 U1 1 SOP28PW socket Enplas: OTS-28-0.65-01
