Hardware
B.26 MSP-TS430PN80
NOTE: For MSP430F47x and MSP430FG47x devices:
Connect pins 7 and 10 (GND) externally to DV
SS
(see data sheet).
Connect load capacitance on V
ref
pin 60 when SD16 is used (see data sheet).
For use of BSL: connect pin 1 of BOOST to pin 58 of U1 and pin 3 of BOOST to pin 57 of U1.
Figure B-52. MSP-TS430PN80 Target Socket Module, Schematic
