MSP-TS430RHB32A
www.ti.com
66
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-12. MSP-TS430RHB32A Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 PCB 1 76.9 x 67.6 mm MSP-TS430RHB32A Rev. 1 2 layers, red solder mask
2 D1 1 green LED, DIODE0805 P516TR-ND
3 JP1, JP2 2 2-pin header, male, TH SAM1035-02-ND place jumper on header
4 JP3, JP4,
JP5, JP6,
JP7, JP8,
JP9
7 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
(SBW)
5 R1, R4 2 0R, 0805 541-0.0ATR-ND
6 C8 1 2.2nF, CSMD0805 490-1628-2-ND DNP
7 R6, R8, R9,
R10, R11,
R12, R13,
R14
8 10k, 0805 311-10KARTR-ND DNP
8 C12 1 10uF, CSMD0805 445-1371-2-ND
9 R2 1 20k/0.1%, 0805 P20KDACT-ND
10 R5 1 47K, 0805 311-47KARTR-ND
11 C13, C14 2 100nF, CSMD0805 311-1245-2-ND
12 R3 1 330R, 0805 541-330ATR-ND
13 C9 1 470nF, CSMD0805 445-1357-2-ND
14 J1, J2, J3, J4 1 8-pin header, TH SAM1029-08-ND DNP: headers and
receptacles, enclosed with
kit.
Keep vias free of solder.
15 J1, J2, J3, J4 1 8-pin receptable, TH SAM1213-08-ND DNP: headers and
receptacles, enclosed with
kit.
Keep vias free of solder.
16 JTAG 1 14-pin connector, male, TH HRP14H-ND
17 U1 1 Socket QFN11T032-003 Manuf.: Yamaichi
18 U1 1 MSP430i2041TRHB DNP: enclosed with kit.
Is supplied by TI
19 J5 1 3-pin header, male, TH SAM1035-03-ND
20 Rubber stand
off
4 Buerklin: 20H1724 apply to corners at bottom
side
