Hardware
Table B-34. MSP-TS430PZ100C Bill of Materials
Pos. Ref Des
Number
Per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP: C1, C2
1.1 C3, C4 2 47pF, SMD0805 DNP: C3, C4
2 C6, C7 2 10uF, 6.3V, Tantal Size B 511-1463-2-ND
3
C5, C11,
C13, C14,
C19, C20
6 100nF, SMD0805 311-1245-2-ND
3.1
C10, C12,
C18,17
0 100nF, SMD0805 311-1245-2-ND DNP: C10, C12,C18, C17
4 C8 1 2.2nF, SMD0805 Buerklin 53 D 292
5 C9 1 470nF, SMD0805 478-1403-2-ND
6 D1 1 green LED, SMD0805 P516TR-ND
7 J1, J2, J3, J4 4 25-pin header, TH SAM1029-25-ND
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
7.1 4 25-pin header, TH SAM1213-25-ND
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
8 J5, J6 2 3-pin header, male, TH SAM1035-03-ND
9
JP5, JP6,
JP7,
JP8,JP9,
JP10
6 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
10 JP1, JP2 2 2-pin header, male, TH SAM1035-02-ND place jumper on header
10.1 JP4 1 2-pin header, male, TH SAM1035-02-ND place jumper on header
11 JP3 1 3-pin header, male, TH SAM1035-03-ND place jumper on pins 1-2
12 10 Jumper 15-38-1024-ND
Place on: JP1, JP2, JP3, JP4, JP5, JP6,
JP7, JP8, JP9, JP10
13 JTAG 1 14-pin connector, male, TH HRP14H-ND
14 BOOTST 1 10-pin connector, male, TH HRP10H-ND DNP, keep vias free of solder
15 Q1 0 Crystal
DNP: Q1
Keep vias free of solder
16 Q2 1 Crystal DNP: Q2 Keep vias free of solder
17 R3, R7 2 330 Ohm, SMD0805 541-330ATR-ND
18
R1, R2, R4,
R6, R8, R9,
R10, R11,
R12
3 0 Ohm, SMD0805 541-000ATR-ND DNP: R6, R8, R9, R10, R11, R12
19 R5 1 47k Ohm, SMD0805 541-47000ATR-ND
20 U1 1 Socket: IC357-1004-53N Manuf.: Yamaichi
21 PCB 1 79.5 x 99.5 mm MSP-TS430PZ100C Rev 1.0 2 layers
22
Rubber stand
off
4 Buerklin: 20H1724 apply to corners at bottom side
23 MSP430 2 MSP430F643x
DNP: enclosed with kit. Is supplied by TI.
24 C16 1 4.7 nF SMD0603 Buerklin 53 D 2042
26 D3, D4 2 LL103A Buerklin: 24S3406
27 JP11 1 4-pin header, male, TH SAM1035-04-ND Place jumper on Pin 1 and Pin 2
28 C15 1 4.7 uF, SMD0805 Buerklin 53 D 2430
29 C21 1 220nF, SMD0805 Buerklin 53 D 2381
