MSP-TS430PW14
www.ti.com
38
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-2. MSP-TS430PW14 Bill of Materials
Position Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
2 C7 1 10uF, 10V, Tantal Size B 511-1463-2-ND
3 C3, C5 1 100nF, SMD0805 478-3351-2-ND DNP: C3
4 C8 0 2.2nF, SMD0805 DNP
5 D1 1 green LED, SMD0603 475-1056-2-ND
6 J1, J2 0 7-pin header, TH
DNP: Headers and receptacles
enclosed with kit. Keep vias free of
solder
SAM1029-07-ND : Header
SAM1213-07-ND : Receptacle
7
J3, J5, J7,
J8, J9, J10,
J11, J12
8 3-pin header, male, TH SAM1035-03-ND
Place jumpers on headers J5, J7, J8,
J9, J10, J11, J12; Pos 1-2
8 J4, J6 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 9 Jumper 15-38-1024-ND Place on: J5, J7-J12; Pos 1-2
10 JTAG 1
14-pin connector, male,
TH
HRP14H-ND
12 Q1 0 Crystal
Micro Crystal MS1V-T1K
32.768kHz, C(Load) =
12.5pF
DNP: keep vias free of solder
13 R2, R3 2 330 Ω, SMD0805 541-330ATR-ND
15 R5 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: OTS-14-0.65-01 Manuf.: Enplas
17 PCB 1 56 x 53 mm 2 layers
18
Adhesive
plastic feet
4
Approximately 6mm width,
2mm height
For example, 3M
Bumpons Part No. SJ-
5302
Apply to corners at bottom side
19 MSP430 2 MSP430F2013IPW DNP: enclosed with kit, supplied by TI
