Texas Instruments MSP430 User Guide

MSP-TS430PW20 www.ti.com
48
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-6. MSP-TS430PW20 Bill of Materials
Pos. Ref Des
No. Per
Board
Description Digi-Key Part No. Comment
1 PCB 1 90.0 x 92.5 mm "MSP-TS430PW20" Rev. 1.1 2 layers, green solder mask
2
JP1, JP9,
JP13, JP14,
JP15
5 2-pin header, male, TH SAM1035-02-ND place jumper on header
3 JP17, JP18 2 2-pin header, male, TH SAM1035-02-ND place jumper on one pin only
4 JP2, JP10 2 2-pin header, male, TH SAM1035-02-ND DNP, keep pads free of solder
5 J1 1 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
6
JP3, JP4, JP5,
JP6, JP7, JP8
6 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
7 JP16 1 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
8 J2 1 3-pin header, male, TH SAM1035-03-ND
9 JP11 1 2x3pin header, male, TH SAM1034-03-ND
PW20: Place jumpers on pins
1-3 and 2-4
PW16: Place jumpers on pins
3-5 and 4-6
10 R2, R8, R9 3 0R, 0805 541-0.0ATR-ND DNP
11 R3, R13 2 0R, 0805 541-0.0ATR-ND
12 C5 1 1.1nF, CSMD0805 490-1623-2-ND
13 C7 1 1uF/10V, CSMD0805 490-1702-2-ND
14 R7, R15 1 10k, 0805 541-10KATR-ND
15 R4 1 47k, 0805 541-47KATR-ND
16 C6, C11 2 100nF, CSMD0805 490-1666-1-ND
17 C8, C9 2 12p, DNP, CSMD0805 BC1257TR-ND DNP
18 R1 1 330R, 0805 541-330ATR-ND
19 R5, R6 2 330R, 0805 541-330ATR-ND DNP
20 R14 1 47k, 0805 541-47KATR-ND DNP
21 SW2 1 EVQ-11L05R P8079STB-ND DNP, Keep vias free of solder
22 SW1 1 EVQ-11L05R P8079STB-ND DNP, Keep vias free of solder
23 J3, J4 2 10-pin header, TH SAM1029-10-ND
DNP: headers are enclosed
with kit.
Keep vias free of solder.
24 J3, J4 2 10-pin receptacle, TH SAM1213-10-ND
DNP: Receptacles are
enclosed with kit.
Keep vias free of solder.
25 TP1, TP2, TP3 3 Test point DNP, keep pads free of solder
26 BSL 1 10-pin connector, male, TH HRP10H-ND
27 JTAG 1 14-pin connector, male, TH HRP14H-ND
28 IC1 1 Socket: OTS-20S-0.65-007 Manuf. Enplas
29 IC1 1 MSP430FR2311IPW20
DNP: Free samples can be
ordered in the TI Store
30 Q2 1 4MHz Crystal 4MHz Buerklin: 78D134
DNP: Crystal is enclosed with
kit
31 Q2 1
MSV3V-T1R (32.768KHz /
20ppm / 12.5pF)
DNP: Crystal is enclosed with
kit
32 D1 1
green LED, HSMG-C170
DIODE0805
516-1434-1-ND Avago, Farnell 5790852
33 D3 1 red LED, DIODE0805 DNP
34 D2 1 yellow LED, DIODE0805 DNP
35
Rubber stand
off
4 Buerklin: 20H1724 apply to corners at bottom side
