Connector J5
External power connection
Remove R8 and jumper R9
D1
LED connected to pin 12
Jumper J6
Open to disconnect LED
Orient Pin 1 of MSP430 device
Jumper J7
Open to measure current
Connector JTAG
For JTAG Tool
Connector BOOTST
For Bootloader Tool
www.ti.com MSP-TS430PZ100
125
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Figure B-61. MSP-TS430PZ100 Target Socket Module, PCB
