Hardware
Table B-3. MSP-TS430L092 Bill of Materials
Pos. Ref Des No.
No. Per
Board
Description Digi-Key Part No. Comment
1 C1, C2 2 330nF, SMD0603
2 C5 1 100n, SMD0603
3 C6 1 10u, SMD0805
4 C10 1 100n, SMD0603
5 EEPROM1 1 M95512 SO08 (SO8) ST Micro M95160R Digikey: 497-8688-1-ND
7 J1, J2 2 7-pin header, TH
DNP: headers and receptacles
enclosed with kit. Keep vias
free of solder.
SAM1213-07-ND : Header
SAM1035-07-ND : Receptacle
8 J3 1 3-pin header, male, TH SAM1035-03-ND
9 J4, J5 2 FE4L, FE4H 4 pol. Stiftreihe DNP; Keep vias free of solder.
11 J13 1 MICRO_STECKV_10
Reichelt: MicroMaTch-
Connector: MM FL 10G
12 JP1, JP2,JP3 3 2-pin header, male, TH SAM1035-02-ND place jumper on header
15 L1 1 33uH, SMD0806 LQH2MCN330K02L Farnell: 151-5557
16 LED1, LED4 2 LEDCHIPLED_0603 Farnell: 1686065
17 Q2 1 BC817-16LT1SMD BC817-16LT1SMD SOT23-BEC
18 R0, R6, R7 3 2K7, SMD0603
19 R1 1 1k, SMD0603
20 R2 1 47k, SMD0603
21
R4,R5, R8,
R10, RC, RD
6 10k, SMD0603
22 RA 1 3.9k, SMD0603
23 RB 1 6.8k, SMD0603
24 U1 1
14 Pin Socket - IC189-0142-
146
Manuf. Yamaichi
22 MSP430 2 MSP430L092PWR
DNP: Enclosed with kit. Is
supplied by TI.
