Hardware
Table B-8. MSP-TS430RGE24A Bill of Materials (BOM)
Position Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 PCB 1 90.0 x 92.5 mm
"MSP-TS430RGE24A" Rev.
1.0
2 layers, red solder mask
2
JP1, JP9,
JP13, JP14,
JP15
5 2-pin header, male, TH SAM1035-02-ND place jumper on header
3 JP17, JP18 2 2-pin header, male, TH SAM1035-02-ND place jumper on one pin only
4 JP2, JP10 2 2-pin header, male, TH SAM1035-02-ND
DNP, keep pads free of
solder
5 J1 1 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
6
JP3, JP4,
JP5, JP6,
JP7, JP8,
JP16
7 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
7 J2 1 3-pin header, male, TH SAM1035-03-ND
8 R2, R8, R9 3 0R, 0805 541-0.0ATR-ND DNP
9 R3, R13 2 0R, 0805 541-0.0ATR-ND
10 C5 1 1.1nF, CSMD0805 490-1623-2-ND
11 C7 1 1uF/10V, CSMD0805 490-1702-2-ND
12 R7, R15 1 10k, 0805 541-10KATR-ND
13 R4 1 47k, 0805 541-47KATR-ND
14 C6, C11 2 100nF, CSMD0805 490-1666-1-ND
15 R1 1 330R, 0805 541-330ATR-ND
16 R5, R6 2 330R, 0805 541-330ATR-ND DNP
17 R14 1 47k, 0805 541-47KATR-ND DNP
18 C8, C9 2 DNP, CSMD0805 DNP
19 SW2 1 EVQ-11L05R P8079STB-ND
DNP, Keep vias free of
solder. Lacon: 1251459
20 SW1 1 EVQ-11L05R P8079STB-ND
DNP, Keep vias free of
solder, Lacon: 1251459
21 J3, J4, J5, J6 4 6-pin header, TH SAM1029-06-ND
DNP: headers enclosed in
kit.
Keep vias free of solder.
22 J3, J4, J5, J6 4 6-pin receptacle, TH SAM1213-06-ND
DNP: receptacles enclosed in
kit.
Keep vias free of solder.
23
TP1, TP2,
TP3
3 Test point
DNP, keep pads free of
solder
24 BSL 1 10-pin connector, male, TH HRP10H-ND
25 JTAG 1 14-pin connector, male, TH HRP14H-ND
26 IC1 1 Socket:QFN-24B-0.5-0.1c Manuf. Enplas
27 IC1 1 MSP430FR2433IRGER
DNP: Free samples can be
ordered in the TI Store
28 Q2 1
DNP: MS3V-TR1
(32,768kHz/ 20ppm/12,5pF)
depends on application
DNP: Micro Crystal, enclosed
in kit. Keep vias free of solder
29 D1 1
green LED, HSMG-C170
DIODE0805
516-1434-1-ND Avago, Farnell 5790852
30 D3 1 red (DNP), DIODE0805 DNP
31 D2 1 yellow (DNP), DIODE0805 DNP
32
Rubber stand
off
4 Buerklin: 20H1724
Apply to corners at bottom
side
