Table 1-1. Individual Kit Contents, MSP-TS430xx (continued)
Part Number Socket Type Supported Devices Included Devices Headers and Comment
MSP-TS430PM64A
(red PCB)
64-pin PM
(QFP ZIF)
MSP430F41x2 2 x MSP430F4152IPM
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430PM64D
(white PCB)
64-pin PM
(QFP ZIF)
MSP430FR413x, MSP430FR203x 2 x MSP430FR4133IPM
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430PM64F
(purple PCB)
64-pin PM
(QFP ZIF)
MSP430FR6972
None. Free samples can
be ordered in the TI Store.
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430RGC64B
(blue PCB)
64-pin RGC
(QFN ZIF)
MSP430F530x 2 x MSP430F5310IRGC
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430RGC64C
(black PCB)
64-pin RGC
(QFN ZIF)
MSP430F522x, MSP430F521x,
MSP430F523x, MSP430F524x,
MSP430F525x
2 x MSP430F5229IRGC
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430RGC64USB
(green PCB)
64-pin RGC
(QFN ZIF)
MSP430F550x, MSP430F551x,
MSP430F552x
2 x MSP430F5510IRGC
or
2 x MSP430F5528IRGC
Eight PCB 1×16-pin headers (four
male and four female)
MSP-TS430PN80
(green PCB)
80-pin PN
(QFP ZIF)
MSP430F241x, MSP430F261x,
MSP430F43x, MSP430F43x1,
MSP430FG43x, MSP430F47x,
MSP430FG47x
2 x MSP430FG439IPN
Eight PCB 1×20-pin headers (four
male and four female)
MSP-TS430PN80A
(red PCB)
80-pin PN
(QFP ZIF)
MSP430F532x 2 x MSP430F5329IPN
Eight PCB 1×20-pin headers (four
male and four female)
MSP-TS430PN80B
(blue PCB)
80-pin PN
(QFP ZIF)
MSP430F599x 2 x MSP430F5994IPN
Eight PCB 1×20-pin headers (four
male and four female)
MSP-TS430PN80USB
(green PCB)
80-pin PN
(QFP ZIF)
MSP430F552x, MSP430F551x 2 x MSP430F5529IPN
Eight PCB 1×20-pin headers (four
male and four female)
MSP-TS430PZ100
(green PCB)
100-pin PZ
(QFP ZIF)
MSP430F43x, MSP430F43x1,
MSP430F44x, MSP430FG461x,
MSP430F47xx
2 x MSP430FG4619IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100A
(red PCB)
100-pin PZ
(QFP ZIF)
MSP430F471xx 2 x MSP430F47197IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100B
(blue PCB)
100-pin PZ
(QFP ZIF)
MSP430F67xx 2 x MSP430F6733IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100C
(black PCB)
100-pin PZ
(QFP ZIF)
MSP430F645x, MSP430F643x,
MSP430F535x, MSP430F533x
2 x MSP430F6438IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100D
(white PCB)
100-pin PZ
(QFP ZIF)
MSP430FR698x(1),
MSP430FR688x(1)
2 x MSP430FR6989IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ5x100
(green PCB)
100-pin PZ
(QFP ZIF)
MSP430F543x, MSP430BT5190,
MSP430SL5438A
2 x MSP430F5438IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100USB
(green PCB)
100-pin PZ
(QFP ZIF)
MSP430F665x, MSP430F663x,
MSP430F563x
2 x MSP430F6638IPZ
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PZ100AUSB
(blue PCB)
100-pin PZ
(QFP ZIF)
MSP430FG662x, MSP430FG642x
None. Free samples can
be ordered in the TI Store.
Eight PCB 1×25-pin headers (four
male and four female)
MSP-TS430PEU128
(green PCB)
128-pin PEU
(QFP ZIF)
MSP430F677x, MSP430F676x,
MSP430F674x, MSP430F677x1,
MSP430F676x1, MSP430F674x1
2 x MSP430F67791IPEU
Four PCB 1x26-pin headers (two
male and two female) and four
PCB 1x38-pin headers (two male
and two female)
See the device data sheets for device specifications. Device errata can be found in the respective device
product folder on the web provided as a PDF document. Depending on the device, errata may also be
found in the device bug database at www.ti.com/sc/cgi-bin/buglist.cgi.
