Texas Instruments MSP430 User Guide

www.ti.com MSP-TS430PZ100AUSB
149
SLAU278Y–May 2009–Revised March 2016
Submit Documentation Feedback
Copyright © 2009–2016, Texas Instruments Incorporated
Hardware
Table B-38. MSP-TS430PZ100AUSB Bill of Materials (continued)
Pos. Ref Des
No. Per
Board
Description Digi-Key Part No. Comment
38 R33 1 1k4 / 1k5 SMD0603 Buerklin: 07E612
39 R34, R35 2 27R SMD0603 Buerklin: 07E444
40 R36 1 33k SMD0603 Buerklin: 07E740
41 R5 1 47k Ohm, SMD0805 541-47000ATR-ND
42
R6, R8, R9,
R12
4 0 Ohm, SMD0805 541-000ATR-ND DNP
43 S1, S2 1 PB P12225STB-ND DNP
44 S3 1 PB P12225STB-ND
45 TP1, TP2 2 Test point DNP, Keep vias free of solder
46 U1 1 Socket: IC357-1004-53N Manuf.: Yamaichi
47 USB1 1 USB Receptacle FARNELL: 117-7885
48
Insulating disk
for Q2
1 Insulating disk for Q2 ettinger.de 70.08.121
49
Rubber stand
off
4 Buerklin: 20H1724 Apply to corners at bottom side
