Textron JACOBSEN GP400 - Component Location

HYDRAULICS
4252490-Rev A 6-5
6
Component Location
See Figures 6-1 and 6-2.
Figure 6-1: Component Location—Front
1 Center Lift Cylinder 4 Lift Valve 7 Right Front Lift Cylinder
2 Reel Valve Unit 5 Soft Drop Valve
3 Hydraulic Oil Charge Filter Assembly 6 Left Front Lift Cylinder
TN3653, TN3765, TN3771
6
4
2
3
7
1
5
