Textron JACOBSEN GP400 Technical/Repair Manual

6-12 4252490-Rev A
HYDRAULICS
6
Hydraulic Schematic (2WD)
See Figures 6-8 through 6-12.
Figure 6-8
Traction
Pump
Suction
Strainer
Hydraulic Tank
125 Micron
Check
Valve
A
B
Engine
3400 rpm
Oil
Cooler
2 psi
Crack
Bypass
Gear
Pump
TN3031
Charge
Relief Valve
150–210 psi
Tow
Valve
0.33 ci
M1
1
2
3
4
5
Tank Fill Cap
Assembly
0.40 ci
0.92 ci
Implement
Relief Valve
800 psi
Check
Valve
Charge Pump
M3V1
M2M4L1S
51 psi
Crack
Bypass
29 psi
Crack Bypass
Switch
10 Micron
Filter
6
7
Charge
Filter
10 Micron
Test
Port
