Textron JACOBSEN GP400 - Mow Circuit Schematic

HYDRAULICS
4252490-Rev A 6-25
6
Mow Circuit Schematic
See Figure 6-16.
Figure 6-16
1 Operating Pressure Oil from Gear Pump 3 Right and Left Reel Motor Case Drain Oil to Hydraulic Tank
2 Return Oil to Lift Valve (Port P) 4 Center Reel Motor Case Drain Oil to Hydraulic Tank
Reel Valve Unit
Relief Valve
3020 psi
Right
Reel
Motor
T
B
1
2
3
4
0.020 in.
Check
Valve
Reel
Valve
Backlap
Enable Switch
145 Micron
Filter
P
A
Left
Reel
Motor
Center
Reel
Motor
0.60
ci
0.60
ci
0.60
ci
TN3072
Reel
Speed Control
Valve
Operating Pressure Oil Return OilInlet or Drain Oil
