SPECIFICATIONS AND GENERAL INFORMATION
4252490-Rev A 2-3
2
Component Location
See Figure 2-4.
!
CAUTION
Figure 2-4: Component Location
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Fuel Tank 4 Park Brake Lever 7 Steering Wheel 10 Right Cutting Unit
2 Hydraulic Tank 5 OPS 8 Traction Pedal 11 Center Cutting Unit
3 Instrument Panel 6 Seat 9 Left Cutting Unit
TN3653
6
7
5
9
10
8
2
1
3
4
11
