Textron JACOBSEN GP400 Technical/Repair Manual

ENGINE
4252490-Rev A 3-3
3
Component Location
Diesel Models
See Figures 3-1 and 3-2.
Figure 3-1: Component Location—Left Side
1 Speed Control Plate 5 Air Cleaner Assembly 9 Starter 13 Thermostat
2 Fuel Shutoff Solenoid 6 Coolant Recovery Bottle 10 Engine Oil Pressure Switch 14 Engine Temperature Sensor
3 Radiator Drain Plug 7 Alternator 11 Engine Oil Filter 15 Fan Belt
4 Radiator Fill Cap 8 Muffler 12 Engine Oil Fill Cap
TN3769, TN3944, TN3943
5
12
15
1
13
7
11
9
8
6
4
14
2
10
3
