HYDRAULICS
4252490-Rev A 6-19
6
Steering Circuit Schematic
See Figure 6-13.
Figure 6-13
1 Operating Pressure Oil from Charge Pump (Traction
Pump Port V1)
2 Return Oil to Oil Cooler and Hydraulic Tank
Steering Cylinder
Steering Unit
Steering Valve
Check
Valve
TN3069
3.84
ci
1
2
RL
TP
Operating Pressure Oil
Return Oil
Metered Oil
