- 5 -
Functions of function mode
FUNCTION switch : Turns the function mode on and off. Press it for approximately 2 seconds until a
beeping sound is made to turn the function mode on. When the function mode is
on, press to turn it off (no need to hold for 2 seconds).
ENTER switch : Used to change the displayed menu, input values into memory and store the
changed data in memory.
CHANGE switch : Used to change the stored data. When this switch is pressed, the displayed data
is deleted and the cursor blinks. Then input new data.
ROTATION switch : Used to select parameters to be inputted. When this switch is pressed, the
parameters to be inputted are displayed in order. The displayed parameters are
different according to the setting menu.
Example : AUTO→FREQ→MANU→SYNC
・→0→1→2→ ･ ･ ･ →8→9
38400→4800→9600→19200
SHIFT switch : Used to move the digit when inputting a value of many numerals. By using this
switch, the cursor moves from the high digit to the low.
