- 30 -
(3) COMM.: For the communication between instrument and PC
① Communication-Type : Set the communication type (USB/RS232C)
☞
‘3.7 PC Connection Method’
② RS-232C Parameter : Set the parameters of RS-232C.
This menu is indicated when set communication type to RS-232C.
(refer to ① Communication-Type)
☞
‘3.8 RS-232C Parameters’
③ CS900 ON/OFF : Set the data communication methods.
This menu is indicated when set communication type to RS-232C.
(refer to ① Communication-Type)
☞
‘3.9 Data Communication Methods’
④ Delimiter : Set the end code of communication.
☞
‘3.10 Remote Command Terminal Codes’
(4) DISPLAY: For the LCD Screen
① Display Mode : Set the table colors.
☞
‘3.2 Table Colors’
② Auto Panel Light : Set whether to use the function that controls of panel light
ON/OFF automatically or not.
☞
‘3.19 Panel Light Control’
③ Beep ON/OFF : Set whether to beep out or not.
☞
‘3.16 Buzzer’
④ Luminance Format : Set the format of luminance output (decimal/exponential)
☞
‘3.17 Luminance Display Format’
⑤ Luminance Decimal : Set the digit of luminance out in decimal.
This menu is indicated when set the luminance format to decimal.
(refer to ④ Luminance Format)
☞
‘3.17.1 Luminance Display Format’
(5) MAINTAIN: For the maintenance
① Maintenance Display : Set whether to display maintenance reminder screen or not.
☞
‘3.18 Maintenance Reminder Screen’
② Memory AllClear : Be used when delete measured data and standard data for
calculation of DIF. value.
☞
‘3.20 Batch Deletion of Measurement and DIF Standard Data’
・ Each time the [ENTER] switch is pressed, the displayed setting item changes. Continue
pressing until the desired item is displayed.
・ In function mode, the switch functions are those listed below the switches. In the
following descriptions, switches will be referenced by the wording below them.
