23
COMPONENTS
(5) TONO measurement value:
Displays ocular pressure measurement values.
For one eye, three measurement values are displayed on the screen,
and thereafter the oldest measurement value is deleted.
White figures: When the measurement was done correct.
[ ]Yellow figures: When the reliability of measurement is low.
ERROR: When the measurement was not done correctly.
OVER: When the measurement range is exceeded.
(6) TONO average value:Displays the average value of ocular pressure measurements. Inte-
ger/decimal representation of the average value can be selected on
the setting menu (see page 82).
(7) PACHO measurement value:
Displays the cornea thickness measurement value.
Only the latest measurement data is displayed in the screen.
(8) Number of TONO/PACHO measurements:
Displays the number of ocular pressure and cornea thickness mea-
surements.
(9) Function menu: Displays the function button under TONO/PACHO mode.
For details, see "CONTROL PANEL COMPONENTS (TONO/PACHO
MODE)" on page 16.
(10) Count change mark:In the AUTO measurement, the number of measurements can be
selected between "single measurement" and "the previously set
number of measurements". For details, see "CHANGING THE NUM-
BER OF MEASUREMENTS" on page 141. This is not displayed
under MANUAL mode.
: Single measurement
: Previously set number of measurements
(11) Alignment mark: Indicates the starting area of auto alignment.
(12) Outer alignment mark: Used to get coarse alignment in aiming at the patient's eye.
(13) Measuring range mark:
The measuring range set by the 30/60 button is displayed. This is not
displayed under PACHO mode.
(14) Ocular Pressure (Value unit) Mark:
Indicates the unit of the measured ocular pressure value.
In the INITIAL MENU screen, the unit can be selected. (see p.48)
This is not displayed under PACHO mode.
(15) Selected measuring eye mark:
Selected patient's eye is shown.
:Both eyes are measured continuously.
:Only the right eye is measured. When fully
automatic measurement mode is selected, only the right
eye is measured repeatedly.
:Only the left eye is measured. When fully auto-
matic measurement mode is selected, only the left eye is
measured repeatedly.
continuous measurement is set in initial settings.
After or is selected, automatically return to initial setting
(continuous measurement), if printing is carried out.
R L
R R/K T/P
L R/K T/P
R L
R L
To Next Page
