72
PREPARATIONS
SETTING AXIS STEP
The axial angle step can be selected from 1
° or 5°. Before shipment, it is set to "1°."
1 Press the of the control panel and get the "SETTING MENU (R/K)
screen." "CONT. MEAS." is highlighted, and "ON" and "OFF" are displayed on the right.
The cursor shows the set content.
2 Press the Set item change button and bring the cursor to "AXIS STEP." figures of
AXIS are displayed on the right. Set figures are highlighted.
3 Press the Set value change button or and bring the cursor to the figure of
desired AXIS:
1 : The display step is set to 1
° units.
5 : The display step is set to 5
° units.
4 Press the Set item change button ; cursor moves to the next item (VD).
Press the Set item change button ; the cursor moves to the previous item (STEP).
5 To exit from the menu, press and return to the MEASUREMENT screen.
MENU button
EXIT
To Next Page
