4. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-33027

(Revised on OCT. 2013)

4.1 DISC CUTTER (B-EX204-QM-R)

4- 5

4. Remove the Strip Plate.

5. Put the Cord Bush onto the Harness Ass’y in the orientation as shown below.

6. Connect the Harness Ass’y to CN1 on the Cutter I/F PC Board.

Strip Plate

Cord Bush

Harness Ass’y

CN1

Harness Ass’y

Cord Bush

Cutter I/F PC Board
