Continued
red
Cause
Solution
ON
- The value set for the Window
Increments parameter has been
exceeded
- Check that the set value for the
Window Increments parameter is
appropriate for the automation task;
see Chapter “Window increments” on
Page 126
- the ambient temperature defined under
the corresponding article number falls
below or exceeds the permissible value
range
- Take appropriate measures to ensure
the permissible ambient temperature
range can be maintained at all times
- The internally calculated PROFIsafe
telegram is faulty
- Power supply OFF/ON. If the error
persists after this measure, the
measuring system must be replaced
- Double magnetic scanning system: the
electrically permissible speed has been
exceeded according to the product data
sheet
- Bring the speed into the permissible
range. Acknowledge the fault via
power supply OFF/ON
Repeating
3x 5 Hz
- Parameterization error
- F-parameterization incorrect, e.g.
PROFIsafe destination address
F_Dest_Add incorrectly set
- Incorrectly configured
F_iPar_CRC value
- Check measuring system
configuration; at least one module
must be configured.
- Check station address
- Check value range of scaling
parameters
- PNO configuration: The parameters
"Measuring range in steps" and
"Number of steps per revolution" must
be selected so that the quotient of both
parameters is a power of two.
- PNO configuration: Check mechanism
of the master sign-of-life
- PNO configuration: Check setting of
the parameter Tolerated sign-of-
life faults
- Check PROFIsafe destination address
set. Valid PROFIsafe destination
addresses: 1 – 255, see Chapter
PROFIsafe destination address
“F_Dest_Add on Page 20
- The checksum calculated for the
specified iParameter set is incorrect or
was not included in the configuration
