Continued
Byte
Parameter
Data type
Description
Page
3-6
Scaling:
Measuring units
per revolution
Unsigned32
Number of steps per revolution
Default value: 8192
Value range: 2-8192
Class 4
48
7-10
Scaling: Total
measuring range
Unsigned32
No. of steps/revolution * No. of revolutions
Default value: 536870912
Value range: 4-536870912
Class 4
48
11
Tolerated sign-of-
life errors
Unsigned8
Max. tolerated errors of control
Default value: 1
Value range: 0-255
(only in compatibility mode)
49
12
Normalization of
speed
Unsigned8
Velocity output unit
0: Steps/sec
1: Steps/100 msec
2: Steps/10 msec
3: Revolutions per minute
4: N2/N4 normalized
Class 4
50
13
Velocity filter
intensity
Bit-Area
Bit 0-3
Filter intensity value
Default value: 0
Value range: 0-10
50
Velocity filter
type
Bit 4
Filter Type
0: static
1: dynamic
51
14-17
Velocity reference
value N2/N4
(PNU 60000)
Float32
Sets the velocity value for 100%
Default value: 3000 rev./min
Class 4
51
18-21
Preset value
(PNU 65000)
Integer32
Sets the actual position value for the preset
function
Default value: 0
Class 4
52
