turck TBIP-L...-FDIO1-2IOL Series TBIP-L4-FDIO1-2IOL - Part 2 - Tbip-L -Fdio1-2 Iol- Standard I\;O Channels

1
2018/02
TBIP-L…-FDIO-2IOL - Standard DXP-Kanäle
Part 2 – TBIP-L…-FDIO1-2IOL– Standard I/O channels
Table of Contents
1About this user manual 1
1.1 Documentation concept 1
1.2 Target Groups of these Operating Instructions 1
1.3 Additional Documents 1
1.4 Explanation of Symbols Used 2
1.5 Manufacturer and Service 2
2 Properties of the Universal Standard I/O Channels (DXP Channels) 3
2.1 Supply of the Universal Standard I/O Channels 4
2.1.1 Safe Shutdown 4
2.2 Technical Data 4
2.3 Wiring Diagrams 5
2.3.1 In- and Outputs, Pin Assignment C4 and C5 5
2.4 Process Data of the Universal Standard I/O Channels 6
2.4.1 Process image TBPN-L1-FDIO1-2IOL 6
2.5 Parameters 8
2.6 Diagnostics/status 8
2.6.1 LED displays 8
2.6.2 Diagnostic messages 8
