TBPN-L1-FDIO1-2IOL- Safe I/O
9.2 Status and Control Word
9.2.1 Status Word
The status word is mapped to the beginning of the process data.
Bit
15
Bit 
14
Bit
13
Bit
12
Bit 
11
Bit 
10
Bit 
9
Bit 
8
Bit 
7
Bit 
6
Bit 
5
Bit 
4
Bit 
3
Bit 
2
Bit 
1
Bit 
0
- Force
Mode
- - CFG
Error
COM UV
V1
OV
V1
UV
V2
OV
V2
OC
Isys
- CFG
change
d
- - DIAG
Name Value Description
DIAG 0 -
1 Diagnostics available at the device.
CFG 
changed
0 -
1 The device configuration was changed.
OC Isys 0 -
1 Overcurrent at Isys
OV V1/V2 0 -
1 V1 or V2 too high (> 30 V DC).
UV V1/V2 -
V1 or V2 too low (< 18 V DC).
COM 0 -
1 Internal error, the device-internal communi
cation is disturbed.
CFG error 0 -
1 The configuration has been changed incompatibly.
Force Mode
0 -
1 The Force Mode is activated, which means, the actua
l output values may no match
the ones defined and sent by the field bus.
9.2.2 Control Word
The control word has no function.
