Properties of the Universal Standard I/O Channels (DXP Channels)
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
8
2.5 Parameters
2.6 Diagnostics/status
2.6.1 LED displays
2.6.2 Diagnostic messages
Parameter name Value Description
Manual output reset
at overcurrent (SROx)
0 = no A The output switches on automatically after an
overload.
1 = yes The output is manually switched-off and on again.
Activate output
(EN DOx)
0 = no
1 = yes
A
LED LED
GREEN
LED
RED
Meaning Remedy
C4 and C5
(DXP)
Channel is
input
Channel is
output
off off inactive inactive
on off active active
on blink-
ing
Input active
and overload of
the supply volt-
age
-
off blink-
ing
Input inactive
and overload of
the supply volt-
age
Overload of
power supply
Check the sensor supply Both
LEDs at the connector are
flashing
off on - Overload
Diagnostics Description
Overcurrent at
output (SCOx)
Overcurrent at the respective output
