turck TBIP-L...-FDIO1-2IOL Series TBIP-L4-FDIO1-2IOL User Manual

Product description
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
16
3.4 Technical Data
3.4.1 Safety Characteristic Data
3.4.2 General technical data
Characteristic data Value
Performance Level (PL) e EN/ISO 13849-1
Safety category 4 EN/ISO 13849-1
Safety Integrity Level (SIL) 3 IEC/EN 61508
SIL CL 3 EN/IEC 62061
PFH
D
4 × 10
-9
1/h EC/EN 61508; EN/ISO 13849-1
PFD 5 × 10
-6
IEC/EN 61508
MTTF
D
> 2500 years DIN EN ISO 13849-1: 2016
DC 99 %
Permissible duration of use (TM) 20 years DIN EN ISO 13849-1
Maximum on-time 12 months IEC/EN 61508
Max. reaction time in case of shutdown
CIP Safety > local output 25 ms IEC/EN 61508
Local input > CIP Safety 20 ms
Local input <> local output 35 ms
Supply voltage
V1 (incl. electronics supply) 24 V DC
Permissible range 20.428.8 VDC
V2 24 VDC, not used in module, only connected through for
further use
Isolation voltages
V1 to V2 500 V AC
V1/V2 to the field bus  500 V AC
Connectors
Ethernet 2 x M12-connector (OUT), 4-pole, D-coded
Power supply
TBIP-L5-FDIO1-2IOL 7/8" connector, 5-pole
TBIP-L4-FDIO1-2IOL 7/8" connector, 4-pole
Inputs / Outputs M12 connector, 5-pole
Permissible torques
Ethernet 0.6 Nm
I/O channels/supply. 0.8 Nm
Mounting (M6 screws) 1.5 Nm
Protective cap 0.5 Nm
Protocol properties EtherNet/IP™
IP address setting The TBIP-Lx-FDIO1-2IOL has two IP addresses. The first IP
address addresses the safety side (left side) of the device.
The second IP address addresses the non-safety (right
side) of the device.
The last byte of the IP address for the safety side can be set
using the rotary coding switches at the device s.
page 41).
QuickConnect not supported
